100% Straumann Tissue Level Compatible Bioconcept Standard Implant
Head Diameter: 4.8mm
Neck Height: 2.8mm
Surface: S-L-A 6mm
Outside diameter of implant thread: 4.8mm
Inside diameter of implant thread: 4.2mm
| Products Code Comparison|
|Brand: ||Products Code for Order: 013120|
|Head Diameter: 4.8 mm||Neck Height: 2.8 mm|
|Material: Titanium||Length: 6 mm|
|Package: EO(Ethylene Oxide) Sterilized||Surface: S-L-A (Sand-blasted, Large grit, Acid-etched)|
Standard implants 4.8 mm RN can be used for oral endosteal implant indications in the maxilla and mandible, for functional and esthetic rehabilitation of edentulous patients with a minimal ridge width of 7 mm and a minimal mesiodistal gap width between adjacent teeth of 7 mm.
Indication S-L-A 6 mm
Because of the reduced surface area for anchorage in the bone, these implants are to be used solely for the following indications:
----As an additional implant together with longer implants to support implant-borne reconstructions.
----As an auxiliary implant for implant-borne bar constructions supporting full dentures in a seriously atrophied mandible.
>>>> DownLoad the whole Products Catalog for reference
※Guarantee for “Bioconcept” Dental Implants
|We guarantee that all our dental implants will be free replaced after implanting without any reason, whole life guarantee, based on the conditions as below, |
1.Original implant packing and label is needed;
2.A document "Customer Feedback Records" should be filled in.
